Screw Compressor SRP 4030E Flex High Pressure AD - 30 hp direct air

Linhas decorativas
Risco esquerdo
Risco direito

Description

The SRP 4000 Flex High Pressure screw compressor line was specifically developed for industries that prioritize innovative solutions to improve their company's competitiveness. Available in power ratings from 15 to 60 hp, these are the only screw compressors in the domestic market with pressures of up to 20 bar, making them ideal for industries that use fiber laser cutting machines in their production processes. The main advantage of compressed air in this type of process is that it can serve as an auxiliary gas for the cutting process, significantly reducing the operational cost of the laser machine, in addition to being a sustainable and renewable gas solution. In some cases, this can result in up to 70% savings in operational costs. Designed according to current national regulations, the SRP 4000 Flex High Pressure screw compressors are equipped with a disconnector switch in the protective cabin, a 24V electronic panel, protection against hot and moving parts, and air/oil tanks and reservoirs certified by Inmetro, ensuring maximum safety and protection for the user during equipment operation. Available in the options of direct air (AD) and direct air with integrated dryer (ADS), the SRP 4000 Flex High Pressure line reduces costs and increases the productivity of your industry.

Schulz

Code: 970.4073-0

Phase - Voltage

Product codes

Technical File

Product description

Downloads

Technical File

Ícone de seta
Ícone de barras transparentes
Ícone de barras

Technical File

Ícone de barras

Technical File

Phase - Voltage

Three Phase - 380 V

Rated Engine Power

30 hp - 22,5 kW

Maximum Pressure

16 - 20 bar - 1,6 - 2 Mpa

Air Flow

38 - 60 SCFM - 64 - 102 m³/h

Lubricating Oil Volume

3,49 gallons

Recommended Oil

Lub Schulz ISO 68

Air Discharge Connection

1"

Lubricated or Oil Less

Lubricated

Motor Degree of Protection

IP55

Maximum Ambient Temperature

45°C

Application

compressed air

Additional Information

Direct Air Compressor (AD): only compressor

Length of Packaged Product

1,820.00 mm

Width of Packaged Product

950.00 mm

Height of Packaged Product

1,520.00 mm

Gross weight

600.00 kg

Net Weight

580.00 kg

Product description

Ícone de seta
Ícone de barras transparentes
Ícone de barras

Product description

The SRP 4000 Flex High Pressure screw compressor line was specifically developed for industries that prioritize innovative solutions to improve their company's competitiveness. Available in power ratings from 15 to 60 hp, these are the only screw compressors in the domestic market with pressures of up to 20 bar, making them ideal for industries that use fiber laser cutting machines in their production processes. The main advantage of compressed air in this type of process is that it can serve as an auxiliary gas for the cutting process, significantly reducing the operational cost of the laser machine, in addition to being a sustainable and renewable gas solution. In some cases, this can result in up to 70% savings in operational costs. Designed according to current national regulations, the SRP 4000 Flex High Pressure screw compressors are equipped with a disconnector switch in the protective cabin, a 24V electronic panel, protection against hot and moving parts, and air/oil tanks and reservoirs certified by Inmetro, ensuring maximum safety and protection for the user during equipment operation. Available in the options of direct air (AD) and direct air with integrated dryer (ADS), the SRP 4000 Flex High Pressure line reduces costs and increases the productivity of your industry.

Phase - Voltage
Three Phase - 380 V
Rated Engine Power
30 hp - 22,5 kW
Maximum Pressure
16 - 20 bar - 1,6 - 2 Mpa
Air Flow
38 - 60 SCFM - 64 - 102 m³/h
Lubricating Oil Volume
3,49 gallons
Recommended Oil
Lub Schulz ISO 68
Air Discharge Connection
1"
Lubricated or Oil Less
Lubricated
Motor Degree of Protection
IP55
Maximum Ambient Temperature
45°C
Application
compressed air
Additional Information
Direct Air Compressor (AD): only compressor
Length of Packaged Product
1,820.00 mm
Width of Packaged Product
950.00 mm
Height of Packaged Product
1,520.00 mm
Gross weight
600.00 kg
Net Weight
580.00 kg

The SRP 4000 Flex High Pressure screw compressor line was specifically developed for industries that prioritize innovative solutions to improve their company's competitiveness. Available in power ratings from 15 to 60 hp, these are the only screw compressors in the domestic market with pressures of up to 20 bar, making them ideal for industries that use fiber laser cutting machines in their production processes. The main advantage of compressed air in this type of process is that it can serve as an auxiliary gas for the cutting process, significantly reducing the operational cost of the laser machine, in addition to being a sustainable and renewable gas solution. In some cases, this can result in up to 70% savings in operational costs. Designed according to current national regulations, the SRP 4000 Flex High Pressure screw compressors are equipped with a disconnector switch in the protective cabin, a 24V electronic panel, protection against hot and moving parts, and air/oil tanks and reservoirs certified by Inmetro, ensuring maximum safety and protection for the user during equipment operation. Available in the options of direct air (AD) and direct air with integrated dryer (ADS), the SRP 4000 Flex High Pressure line reduces costs and increases the productivity of your industry.
